140 kg Ice Vending Machine

140 kg self-service ice vending machine possesses bagging system and sealing system with ice capacity 140kg. Kayson is a professional manufacturer of vending equipment. This ice cube vending machinery is our main and hot-selling product.It replaces the existing large storage freezers that require truck delivery from ice factories and associated labor for stacking, level maintenance and payment. It also alleviates the current problems that customers may experience with melted, compacted and unpleasant taste ice. This self-service ice vending machine mainly consists of powder coated steel cabinet, coin acceptor, bill validator, system board, ice making system and ice bagging system. When customers fling coin or swing the card, the automatic ice cube vending machinery will sell the edible ice automatically.

1. Luxurious waterproof steel cabinet and stainless steel vending compartment contribute to safety and easy installation of the 140kg self-service ice vending machine.
2. It adopts advanced stable intelligent coin, induction IC card and note selling control technology.
3. This ice cube vending machinery uses efficient spray ice film to make ice, pack ice in bags and seal bags automatically.
4. This automatic vending equipment adopts advanced reverse osmosis purification technology so that the ice quality reaches Chinese national standard.
5. Kayson self-service ice vending machines have got CE approval.
6. Digital vend counter can record the vending situation of the ice cube vending machinery.
7. It is available to add a water filtration system for inlet water if you want.
8. There are two options of bulk ice and bag ice to satisfy different requirements.

Operation and Maintenance Attentions
1. It would be best for customers to send the engineer to our factory for training operation of the 140kg self-service ice vending machine.
2. Kayson offers one year warranty for the broken parts of automatic ice cube vending machinery. Clients can contact us via email or phone for after sales.

Packaging and Transportation
We package this self-service ice vending machine in carton for ordinary order. For bulk order, we use polywood cases for sea or air transportation.

Technical Parameters of 140 kg Ice Vending Machine

Material Stainless steel (304) and powder-coated steel
Dimension 100 cm × 110 cm × 220 cm  (W × D × H)
Bag Dimension 300 mm × 56 mm
Power Supply AC 220V, 50Hz / AC 110V, 60Hz
Phase 3 Phase/Single Phase
Production Capacity 140 kg per day
Ice Cube Size 2.2 cm × 2.2 cm × 2.2 cm
QTY of Ice Cube Mode 540
Type of Compressor 3P
Refrigerant R404a
Ice Making Type Circulated Spray
Cooling System Fan Cooling
Ice Storage Capacity 70 kg to 80 kg
Max. Weight Of Sealed Bag Ice 7 kg
Storage Tank Material SUS 304
Source Water Tap Water
Vending Function IC Card/Bill/Coin/Give Change/GSM Remote Monitor (We can choose according to different needs.)
Ice Vend Type Bulk Ice/Bag Ice
Bag Ice Procedure Automatic packing, counting weight, sealing
Bag Dimension 30 cm × 56 cm/30 cm × 76 cm
Bag Thickness 0.05 mm(single layer)
Bag Ice Weight Range 1 kg to 4 kg
QTY of Bags About 200 pcs
Ice Container Plastic bag or Incubator
Output Speed of Ice 1 kg/5sec
Packing Speed 90 sec per bag
Max. Dimension of Incubator 45 cm × 35 cm × 50 cm (W × D × H)
